Fluke 190-502/AM Color ScopeMeter Color Test tool, 2 Channel, 500MHz

Model: 190-502/AM | UPC: 095969601726

Fluke 190-502/AM Color ScopeMeter Color Test tool, 2 Channel, 500MHz-


Downloads: datasheet manual

Fluke 190-502/AM Color ScopeMeter Color Test tool, 2 Channel, 500MHz

Model: 190-502/AM

This portable oscilloscope offers the same performance as a bench scope with feature rich capabilities to tackle just about any troubleshooting task.

This portable oscilloscope offers the same performance as a bench scope with feature rich capabilities to tackle just about any troubleshooting task.

Your Price $5799.99 USD
Availability 2 to 3 Weeks
Quantity

Add In-House Traceable Calibration to your 190-502/AM

Add In-House Traceable Calibration to your 190-502/AM


Fluke 190-502/AM Offers

Simplify electrical signal analysis and diagnose equipment failures in the field with the Fluke 190-502. The portable oscilloscope offers the same performance as a bench scope with feature–rich capabilities to tackle just about any troubleshooting task. Designed for plant maintenance engineers and technicians, the 190 ScopeMeter® Series goes into harsh and dirty industrial conditions to test everything from microelectronics to power electronics applications.

The Fluke 190-502 two-channel portable oscilloscope features a CAT III 1000V/CAT IV 600V safety rating and is IP-51 rated to withstand harsh environments. Get unprecedented ease-of-use with Connect-and-View™ triggering to capture and analyze waveforms hands free. With 500MHz bandwidth and real-time sampling rates up to 5 GS/sec, you can quickly and easily capture noise and other disturbances to quickly make sense of your signals and eliminate the tedium of troubleshooting.

Features

  • 2 independent floating isolated inputs for making differential measurements
  • Flexibility and convenience of an integrated 5000 count digital multimeter
  • 500MHz bandwidth and 5 GS/sec high-speed sampling
  • CAT III 1000 V/CAT IV 600 V safety rated for high voltage environments
  • Connect-and-View™ for intelligent, automatic triggering on fast, slow and even complex signals
  • ScopeRecord™ Roll mode captures low frequency signal anomalies over minutes, hours, or days
  • TrendPlot™ paperless recorder mode trends meter measurements over days and weeks to identify signal changes
  • Automatic capture and replay of last 100 screens
  • Isolated USB host port for memory devices and PC connectivity
  • Up to 7 hours of standard battery operation and easy-access battery door for quick battery swaps in the field

Applications

  • Automation & Process Control
  • Industrial
  • Maintenance & Repair
  • Motor Drive & Control
  • Test & Measurement

Fluke 190-502/AM Specifications

Bandwidth 500 MHz
Number of Channels 2 channels
Real-time Sample Rate 5 GS
Inputs 4 scope or 2 scope plus DMM input
Independently floating isolated inputs Up to 1000 V CAT III/600 V CAT IV between inputs, references and ground
Input sensitivity 2 mV-100 V/div
Trigger types Connect-and-View™, Free Run, Single Shot, Edge, Delay, Dual Slope, Video, Video Line, Selectable pulse width, N-Cycle
Trigger Source Any scope input channel, or external via DMM input on 190-XX2, 2 channel models
Glitch capture 8 ns
Scope Measurements Cursor: 7, Automatic: 30
Max. Record Length ScopeRecord mode: 30,000 pts, Scope mode: 10,000 pts per input
Persistence Digital persistence giving analog oscilloscope-like waveform decay
Waveform Compare Waveform reference with automatic Pass/Fail testing
Click here for complete specifications on the Fluke 190-502/AM

What's included with the Fluke 190-502/AM

  • Fluke 190-502/AM Two-Channel Color ScopeMeter Color Test Tool
  • BC190 Battery
  • Charger/Mains Adapter
  • Li-ion Battery Pack
  • VPS410 Voltage Probe Sets
  • TL175 Test Leads
  • Hang Strap
  • Multi-Language User's Manual on CD-ROM
  • FlukeView Demo Package
