Fluke 7103-156 Liquid Bath Calibrator, -30 to 125°C

Model: 7103-156 | UPC: 95969128278

Fluke 7103-156 Liquid Bath Calibrator, -30 to 125°C-


Downloads: datasheet manual

Fluke 7103-156 Liquid Bath Calibrator, -30 to 125°C

Model: 7103-156

Worlds smallest portable calibration bath that can be transported with fluid in them. This model uses a fluid medium which eliminates the problems of fit and immersion issues.

Worlds smallest portable calibration bath that can be transported with fluid in them. This model uses a fluid medium which eliminates the problems of fit and immersion issues.

Your Price $8467.00 USD
Availability 1 to 2 Weeks
Quantity

Add In-House Traceable Calibration to your 7103-156

Add In-House Traceable Calibration to your 7103-156


Fluke 7103-156 Liquid Bath Calibrator, -30 to 125°C Offers

Features

  • World's smallest portable calibration baths can be transported with the fluid in them
  • Stable to ±0.03°C or better, depending on the fluid you use
  • Uniformity is ±0.02°C or better for low uncertainties using a reference thermometer
  • Display accuracy has been improved to ±0.25°C for quick calibrations without a reference thermometer
  • With a 48mm (1.9") diameter, 140mm (5.5") deep tank, user can calibrate any type of sensor including short, square, or odd-shaped sensors
  • Problems of fit and immersion are virtually eliminated by using a fluid medium rather than a dry-block calibrator
  • Micro-Baths are perfect for liquid-in-glass and bimetal thermometers
  • All models have RS-232 ports, come with Interface-it software, and can be used with MET/TEMP II software
  • Also included are contacts to calibrate a thermal switch, eight set-point memory storage, ramp-rate adjust, and over-temperature safety cutout
  • Cold Micro-Baths are CFC-free as well as compressor-free

Applications

Ideal for the following applications: Laboratory, Education, R&D, Calibration Labs, Field Calibration

Fluke 7103-156 Specifications

Temperature Range -30 to 125°C (-22 to 257°F)
Stability ±0.03°C @ -25°C; ±0.05°C @ 125°C (oil 5010)
Accuracy ±0.25°C
Uniformity ±0.02°C
Resolution 0.01°C/°F
Heating Time 25 to 100°C: 35 minutes
Cooling Time 25 to -20°C: 45 minutes
Fluid Volume 1.0L
Well Size 2.5" dia. x 5.5" deep (64 x 139 mm) Access opening is 1.9" (48 mm) dia.
Click here for complete specifications on the Fluke 7103-156

What's included with the Fluke 7103-156

  • Fluke 7103-156 Liquid Bath Calibrator, -30 to 125°C
  • Click on a category to view a selection of compatible accessories with the Fluke 7103-156 Liquid Bath Calibrator, -30 to 125°C.

    Fluke 2083 Tank Extension Adapter, 3" 2083
    Tank Extension Adapter for the 6102, 7102 and 7103 Liquid Bath Calibrators.




    Fluke 2085 Spare Tank Lid for the Fluke 7103 2085
    Spare Tank Lid for the Liquid Bath Calibrator.




    Fluke 9317 Carrying Case for Fluke Liquid Bath Calibrators 9317
    Carrying case for the 7102 and 7103 Liquid Bath Calibrator.




    Fluke 5010-1L Silicone Oil, Type 200.50, 1L, -40 to 130°C 5010-1L
    Silicone oil for the 6102, 7102 and 7103 Liquid Bath Calibrators.




    Fluke 5013-1L Silicone Oil, Type 200.20, 1L, 10 to 230°C 5013-1L
    Silicone oil for the Fluke 6102, 7102 and 7103 Liquid Bath Calibrators.
