Fluke 2700G-G20M/C Reference Pressure Gauge with Accreditation, 0 to 3000 PSI

Model: 2700G-G20M/C | UPC: 95969668408

Fluke 2700G-G20M/C Reference Pressure Gauge with Accreditation, 0 to 3000 PSI-


Downloads: datasheet manual

Fluke 2700G-G20M/C Reference Pressure Gauge with Accreditation, 0 to 3000 PSI

Model: 2700G-G20M/C

Rugged and easy to use. Ideal for a wide variety of applications and offers best in class measurement performance suitable for calibrating pressure measurement devices such as pressure gauges, transmitters, transducers, and switches.

Rugged and easy to use. Ideal for a wide variety of applications and offers best in class measurement performance suitable for calibrating pressure measurement devices such as pressure gauges, transmitters, transducers, and switches.

Your Price $1780.00 USD
Availability 2 to 3 Weeks
Quantity

Can be combined with the P5500 series of comparison test pumps to make a complete pressure calibration system. The unique test port design of the P5500 series allows for a hand tight connection without the use of PTFE tape.

Features

  • Easy-to-use interface that allows you to configure the sampling rate, tare value, damping, and auto-off time interval as well as reset the min/max pressure
  • View the remaining battery life
  • Select from 21 different standard engineering units, including bar, in H2O, kPa, MPa, and psi

Application Selection Guide

Fluke 754 Documenting Process Calibrator with HART communication Fluke 721 Dual Sensor Pressure Calibrators Fluke 719PRO Electric Pressure Calibrators Fluke 719 Pressure Calibrator Fluke 718 Series Pressure Calibrators Fluke 717 Series Pressure Calibrators Fluke 700G Series Pressure Test Gauge Fluke 3130-G2M Portable Pneumatic Pressure Calibrators Fluke 2700G Series Pressure Gauges Fluke Deadweight Testers
Model number 754 721/​721Ex 719Pro 719 718 717 700G 3130 2700G Dead-weight Testers
Application
Calibrating pressure transmitters (field) Ideal
Calibrating pressure transmitters (bench) Ideal
Calibrating HART Smart transmitters Ideal
Documenting pressure transmitter calibrations Ideal
Testing pressure switches in the field Ideal
Testing pressure switches on the bench Ideal
Documenting pressure switch tests Ideal
Testing pressure switches with live (voltage) contacts Ideal
Gas custody transfer computer tests Ideal
Verifying process pressure gauges (field) Ideal
Verifying process pressure gauges (bench) Ideal
Logging pressure measurements Ideal
Testing pressure devices using a reference gauge Ideal
Hydrostatic vessel testing Ideal
Leak testing (pressure measurement logging) Ideal
Pressure Calibration Selection Guide

Fluke 2700G-G20M/C Specifications

Pressure Connection 1/4 in NPT Male
Housing Cast ZNAL
Display 5-1/2 digits, 16.53 mm (0.65") high 20-segment bar graph, 0 to 100%
Range 0 to 3000 psi, 0 to 20 MPa
Resolution 0.1 psi, 0.01 bar
Uncertainty (k=2) Positive Pressure: ±0.02% FS
Vacuum: ±0.05% FS
Burst Pressure 10 000 psi, 70 MPa/td>
Media Compatibility Note 3
Power Source 3 x AA Alkaline Batteries
Battery Life 75 hours
Weight 0.56 kg (1.22 lbs)
Dimensions 12.7 x 11.4 x 3.7cm (5 x 4.5 x 1.5")
Click here for complete specifications on the Fluke 2700G-G20M/C

What's included with the Fluke 2700G-G20M/C

  • Fluke 2700G-G20M/C Reference Pressure Gauge with Accreditation, 0 to 3000 PSI
  • Customer Reviews for the Fluke 2700G-G20M/C

    Ask a question about Fluke 2700G-G20M/C Reference Pressure Gauge with Accreditation, 0 to 3000 PSI

    Can be combined with the P5500 series of comparison test pumps to make a complete pressure calibration system. The unique test port design of the P5500 series allows for a hand tight connection without the use of PTFE tape.

    Features

    • Easy-to-use interface that allows you to configure the sampling rate, tare value, damping, and auto-off time interval as well as reset the min/max pressure
    • View the remaining battery life
    • Select from 21 different standard engineering units, including bar, in H2O, kPa, MPa, and psi

    Application Selection Guide

    Fluke 754 Documenting Process Calibrator with HART communication Fluke 721 Dual Sensor Pressure Calibrators Fluke 719PRO Electric Pressure Calibrators Fluke 719 Pressure Calibrator Fluke 718 Series Pressure Calibrators Fluke 717 Series Pressure Calibrators Fluke 700G Series Pressure Test Gauge Fluke 3130-G2M Portable Pneumatic Pressure Calibrators Fluke 2700G Series Pressure Gauges Fluke Deadweight Testers
    Model number 754 721/​721Ex 719Pro 719 718 717 700G 3130 2700G Dead-weight Testers
    Application
    Calibrating pressure transmitters (field) Ideal
    Calibrating pressure transmitters (bench) Ideal
    Calibrating HART Smart transmitters Ideal
    Documenting pressure transmitter calibrations Ideal
    Testing pressure switches in the field Ideal
    Testing pressure switches on the bench Ideal
    Documenting pressure switch tests Ideal
    Testing pressure switches with live (voltage) contacts Ideal
    Gas custody transfer computer tests Ideal
    Verifying process pressure gauges (field) Ideal
    Verifying process pressure gauges (bench) Ideal
    Logging pressure measurements Ideal
    Testing pressure devices using a reference gauge Ideal
    Hydrostatic vessel testing Ideal
    Leak testing (pressure measurement logging) Ideal
    Pressure Calibration Selection Guide

    Fluke 2700G-G20M/C Specifications

    Pressure Connection 1/4 in NPT Male
    Housing Cast ZNAL
    Display 5-1/2 digits, 16.53 mm (0.65") high 20-segment bar graph, 0 to 100%
    Range 0 to 3000 psi, 0 to 20 MPa
    Resolution 0.1 psi, 0.01 bar
    Uncertainty (k=2) Positive Pressure: ±0.02% FS
    Vacuum: ±0.05% FS
    Burst Pressure 10 000 psi, 70 MPa/td>
    Media Compatibility Note 3
    Power Source 3 x AA Alkaline Batteries
    Battery Life 75 hours
    Weight 0.56 kg (1.22 lbs)
    Dimensions 12.7 x 11.4 x 3.7cm (5 x 4.5 x 1.5")
    Click here for complete specifications on the Fluke 2700G-G20M/C

    What's included with the Fluke 2700G-G20M/C

  • Fluke 2700G-G20M/C Reference Pressure Gauge with Accreditation, 0 to 3000 PSI
